MIDILLI MIDI Router, Hub, Filter (with Bluetooth)

Description

Meet the smartest way to take control of your MIDI world.

The MIDILLI MIDI Router lets you route messages exactly where you want and in any direction you want — between USB, Bluetooth, DIN and TRS (Type A & B) — with per-interface, per-message type, and per channel filtering that gives you total creative freedom.

Compact, powerful, and ultra-efficient, it’s designed for both stage and studio. Only 106 × 55 × 33 mm (4.17 × 2.17 × 1.3 inches) and 115 grams (4.06 oz).

Say goodbye to messy cables and rigid signal chains — and hello to the most flexible MIDI brain you’ve ever owned.

Every feature is a response to your needs: seamless integration across Bluetooth, USB, DIN, and TRS interfaces, a smart matrix routing system, and message filtering to ensure that every note, beat, and control signal arrives just as you intend.

Check the trailer below (or click here to watch):

Key Features

Multiple MIDI Interfaces:

• 4x MIDI Out (2x MIDI DIN-5, 1x TRS 3.5mm Type-A, 1x TRS 3.5mm Type-B) 🎹
• 1x MIDI In DIN 5 🎶
• 2x MIDI Thru DIN 5 🔄
• 1x USB MIDI (In and Out) 💻
• 1x Bluetooth MIDI (In and Out – BLE 5.0) 📱
• mLink Support: Seamless wireless pairing with other MIDILLI devices, expanding your MIDI ecosystem with zero hassle.

MIDI Routing:

• Forward incoming MIDI messages between MIDI Out, USB MIDI, and Bluetooth MIDI
• Enable or disable interfaces for forwarding
• Select which message types (e.g., Note, Clock, SysEx) to forward
• Select which channels to forward.

Plug & Play:

• No drivers required! Works out of the box with macOS, Windows, Linux, Android, and iOS*
• Powered via USB-C with low power consumption.

*iOS: Bluetooth MIDI or with devices with USB-C connector.

Configurator Software

Only needed when you need to change settings. Available for Windows, macOS, and Linux. Get Configurator here.

Specifications

⚙️ Physical Connections

• 1× MIDI In (DIN-5)
• 2× MIDI Out (DIN-5)
• 1× TRS 3.5mm MIDI Out – Type A
• 1× TRS 3.5mm MIDI Out – Type B
• 2× MIDI Thru (DIN-5)
• 1× USB MIDI (via USB-C)
• 1× Bluetooth MIDI (BLE 5.0)

📦 Dimensions

• Size: 106 × 55 × 33 mm (4.17 × 2.17 × 1.3 inches) (Width × Depth × Height)
• Weight: 115 grams (4.06 oz)

🔌 Power

• 5V, USB-C Powered
• Current: 95 mA (with Bluetooth enabled)
• Current: 75 mA (with Bluetooth off)

Optional Upgrades

• Choose Your Own Color option to match your personal style (you will be contacted for details)

• Custom Device Name so your hub carries your unique identity (you will be contacted for details)



• MIDILLI USB-C to USB-A Cable – 2 Meters
• MIDILLI USB-A to USB-C Adapter
